Outdoor 6CH AHD CCTV Kit 4Mp Cctv Kit Surveillance Camera System
feature:
1. Image Sensor:1/4" 4Megapixel CMOS HD AHD 1440P
2. Resolution:2560*1440
3. Lens:3.6mm 5MP MRT
4. Power supply:DC12V±10%
4. Ingress Protection:IP67
5. Transmission Distance:Over 500M via 75~3 Coaxial Cable
Our advantage:
1. We are an integrated enterprise of industry and trade, have
their own R&D, production and sales team, have a very strong
production capacity, short product delivery time
2. Self-developed private mode products are unique, reliable, and
more market competitive
3. The shell of all products belongs to metal material, high
quality guarantee, long life.
4. We have professional automated waterproof test equipment to
ensure that each camera reaches a waterproof rating of IP67
True night vision technology
Our true night vision technology delivers a clear and bright night
vision effect,
The camera's built-in mechanical infrared filter, Infrared light in
the daytime for superior color reproduction.
At night, The IR filter is automatically removed for enhanced light
sensitivity,
The high quality IR Leds allow each camera to view the environment
even in complete darkness.
AHD DVR kit Parameters:
| Image Sensor | 1/4" 4Megapixel CMOS HD AHD 1440P |
| Resolution | 2560*1440 |
| Min.illumination | 0.002Lux F1.2(AGC ON),0Lux IR on |
| camera Features |
| Lens | 3.6mm 5MP MRT |
| LED | 12pcs Nano LEDS |
| IR Range | 30M |
| Day/Night | Auto(ICR)/Color/ B/W |
| General |
| Power supply | DC12V±10% |
| Transmission Distance | Over 500M via 75~3 Coaxial Cable |
| Ingress Protection | IP67 |
AHD DVR Data:
| Model | TL-CVD7004 | TL-CVD7008 |
| Display Interface | 1 HDMI,1VGA,1BNC |
| Resolution | 1920*1080,1280*1024,1280*720,1024*768,800*600 |
| Display Split | 1/4 | 1/4/8/ |
| Privacy Masking | 4 rectangular zones(each camera) |
| OSD | camera title,Time,Video loss,Camera lock,Motion detection,Recording |
| Video/Audio compression | H.264/G.711 |
Record Rate Main stream
Extra Stream | 720P/960H/D1/HD1/2CIF/CIF(1-25/30fps) |
| CIF/QCIF(1-25/30fps) |
| Record Mode | Manual,Schedule(Regular(continuous),MD),Stop |
| Trigger Events | Recording,PTZ,Tour,Video Push,Email,FTP,Spot,Buzzer&Screen |
| Video Detection | Motion Detection,MD Zones:396(22/8),Video loss&camera Blank |
| Alarm Input | 4 channel | 8 channel |
| Sync Playback | 1/4 | 1/4/8/ |
| Search Mode | Time/Date,MD&Exact search(accurate to second) |
| Backup Mode | USB Device/network |
| Network Ethernet | RJ-45 port(10/100M/1000M) |
| Max User Access | 128 users |
| Smart Phone | iphone,ipad,Android,Windows,Phone |
