White Matel Case High PTZ Speed Dome Camera 36X Optical Zoom
Outdoor
feature:
1. 1/2.5"Prongressive Scan CMOS --2.0MP
2. 18x optical zoom,day version 80m; 22X,day version 100m; 36X,day
version 120m,
3. Night Version:can see the face within 150m,can see the object within 200m
4. Auto IR-cut as per camera’s focus
5. Power recovery function,Guard Position
6. Transparent part is glass,easily cleaning;
7. Support ONVIF 2.0,compatible with Hikvision,Dahua etc.NVR
Shipping
FEDEX, DHL, TNT, UPS, EMS, HongKong Post, Aramex, Air Freight,
Ocean Shipping
How to order from us?
1. Please confirm the model numbers and quantities that you would
like to purchase to our sales person, or email to us.
2. We will send you a Proforma Invoice to specify net cost of
mentioned goods and other relevant charges once you confirm the
order.
3. After you arrange the payment and send us your bank slip, we
will put your order down to production, and let you know the ready
date in 2 days.
4. When the goods are finished, we will send them by air express,
or by sea, or other available shipping methods appointed by
customers, and let you know the tracking number and estimated time
of arrival.
| Camera | Image Sensor | 1/2.8''CMOS |
| Resolution | 1920(H)×1080(V) |
| Pixels | 2.0MP |
| Compression | H.264/JPEG |
| Frame Rate | 25fps~30fps |
| Synchronization | Internal |
| SNR | 54dB |
| Min Illumination | 0Lux(IR ON) |
| Lens | Lens Mount | M12 |
| Lens | 4mm, 6mm, 8mm,12mm ,16mm Optional |
| Viewing Angle | 4mm: 105.94, 6mm: 64.65, 8mm: 48.42, 12mm: 34, 16mm: 19.8 |
| Focus Control | Manual |
| PTZ Parameter | Rotation Speed | Horizontal 0.1~40/S; Vertical 0.1-20/S |
| Preset Speed | Horizontal 40/S; Vertical 20/S |
| Rotation Range | Horizontal 0~360 unlimited rotation; Vertical 0~90 auto 180
reversal |
| A-B two points scan | Random setting |
| A-B two points scan speed | Fast speed/Middle speed/Low speed, speed adjustable |
| Cruise No. | 8 groups(8 presets each group) |
| Presets | 128 |
| Power Memory | Support |
| Guard Position | Support |
| General | Infrared Lamp | 26Lattice Lamps |
| IR Distance | F14 8 pcs Array LED Lights, Effective distance up to 60m |
| Waterproof | IP66 |
| Power Supply | DC 12V 2A |
| Working Temperature | -20C~60C |
| Working Humidity | 10%~90% |
| Power | Day: <10W Night: <15W |
| Material | Aluminum |
| Size((W×H×D)(mm) | 215×200×250 |
| Weight(kg) | 1.9kg |
| Installation | Rack Mounting |
