Full Hd Cctv DVR And NVR AHD 2MP 4 Channel Dvr With Ce RoHS FCC
feature:
2. P2P Plug & Play , Support long-distance surveillance
3. User friendly graphic interface
4. Support iphone, Android windows mobile, PC etc.
5. Support 1pcs *SATA HDD (Max.6TB)
6. QR Code scan sep up. Anytime & anywhere remote viewing live demo and playback.
7. OSD:Camera title,Time,Video loss,Camera lock,Motion
detection,Recording
Our advantage:
1. We are an integrated enterprise of industry and trade, have
their own R&D, production and sales team, have a very strong
production capacity, short product delivery time
2. Self-developed private mode products are unique, reliable, and
more market competitive
3. The shell of all products belongs to metal material, high
quality guarantee, long life.
our service :
1. Products manufacturing
2. 24 hours online,free technical training
3. technical support customised product sourcing
4. 2 years product warranty after-sale service
5. We insist on "quality first", aiming to build up long-term cooperation with our customers. We
always choose better materials for our customers and take at least 3 times strict QC test before shipment. We ensure the pass rate is 100%.
| 60HZ(NTSC) recording | 15FPS/CH @ 1080P; 25FPS/720P,D1,VGA,CIF(real time) | 15FPS/CH @ 1080P,960P
30FPS/CH @ 720P,D1,VGA,CIF(real time) |
| 50HZ(PAL) recording | 12FPS/CH @ 1080P; 25FPS/CH @720P,D1,VGA,CIF(real time) | 12FPS/CH @ 1080P;
25FPS/CH @ 720P,D1,VGA,CIF(real time) |
| Playback | 1-ch 720P,D1,VGA / 4-ch CIF | 1-ch 720P,D1,VGA / 9-ch CIF |
| HDMI output | 1920*1080 |
| VGA output | 1920*1080/1280*1024 / 800*600 |
| BNC output | NTSC:720X480 / PAL:720X576 |
| CDS threshold setup | Support |
| Zoom | Continuous variable |
| Network protocol | P2P , DHCP, DDNS, UPnP, SMTP, HTTP,ONVIF, FAB |
| IE | Windows |
| CMS | Windows / Mac |
| CMS function | 64pcs 32-ch NVR connect,256-ch preview,maximum 1080P,PTZ
control,Network playback,Network backup,Network menu
setup,snapshot,PC record,AVH file playback,AVH file transform to
AVI file,etc. |
| Motion detect | Support |
| Record mode | Time /Sensor / Motion / Motion+Sensor |
| Mobile OS | Windows mobile, iPhone, Android, Symbian, Blackberry |
| Mobile function | 16-ch preview,Maximun resolution is 1080P,Network playback,PTZ
control,snapshot,etc. |
| Listen | Come from 4-ch IPCAM,CMS | Come from 9-ch IPCAM,CMS |
| Audio output | Send to 4-ch IPCAM or CMS | Send to 9-ch IPCAM or CMS |
| Audio input | Come from 4-ch IPCAM | Come from 9-ch IPCAM |
| Alarm email | Support |
| Alarm input | 4-ch from NVR and 4-ch from IPCAM | 4-ch from NVR and 9-ch from IPCAM |
| Alarm output | 1port NVR and 4-ch send to IPCAM | 1port NVR and 9-ch send to IPCAM |
| Hard disc | 1*3000G SATA HDDs |
| Mouse | Support |
| Remoter | Support |
| Keyboard control | Network or RS485 |
| PTZ control | Network or RS485 |
| Network connector | 100M RJ45 |
| DVD-RW | Optional |
| USB connector | 2*2USB 2.0 |
| Language | Two groups selectable,7 languages for each group |
| Power | DC12V 5A |
| Working temperature | -10°C~50°C |
| Size | 300mm(L)×220mm(W)×45mm(H) |
| Weight | 1.9 kg (No hard disc) |
